| case NodeType::SUBTREE_NODE: | ||
| return "SubTree"; | ||
| default: | ||
| return "Undefined"; |
| switch (type) | ||
| { | ||
| case NodeType::ACTION_NODE: | ||
| return "Action"; |
There was a problem hiding this comment.
For actions and condition I would suggest to print the name instead
There was a problem hiding this comment.
Look carefully. This print NodeType, not TreeNode.
NodeType is an enum.
src/behavior_tree.cpp
Outdated
|
|
||
| namespace BT | ||
| { | ||
| void RecursiveVisitor(const TreeNode* node, const std::function<void(const TreeNode*)> visitor) |
src/behavior_tree.cpp
Outdated
| } | ||
| } | ||
|
|
||
| void PrintTreeRecursively(const TreeNode* root_node) |
facontidavide
force-pushed
the
devel_factory
branch
from
e7d2e1a to
3c6ab32
Compare
|
Hi, I realized that we may pass the ResetPolicy by Nodeparameter. This means that I have to consider the extra case of TreeNodes that have both constructors, with and without parameters. |
The unit test contains also the example with SubTree. |
|
What is DecoratorSubtree? |
|
Based on the fact that the difference between a ControlNode and the DecoratorNode differs only in the number of children (only one for the latter), the concept of SubTree is conceptually a Decorator (one child). This node is purely a dummy, as you can see in the implementation. In the future, it may also implement the concept of scoped blackboard i.e. a blackboard that can be seen only by the subtree, but not the parent tree. EDIT: if you prefer, it can be renamed simply SubTreeNode |
It was neither a BehaviorTree itself nor a MetaModel...
facontidavide
force-pushed
the
devel_factory
branch
from
58f0599 to
1d5b179
Compare
|
Do you see the three pending questions above? |
|
The ones I see are about
|
|
What is the purpose of recursiveVisitor? |
|
recursiveVisitor is just an utility to do a ordered for-loop on a node and all its children. A "visitor" is just a user-defined function (or lambda) that does something on a node. For example, imagine that you want to make a snapshot of the state of a the nodes of a tree. std::map<const TreeNode*, NodeStatus> status_by_node;
recursiveVisitor( root_node, [&status_by_node](const TreeNode* node)
{
status_by_node[node] = node->status();
});Or, once the blackboard functionality is added (future PR): // For the time being, consider this pseudo-code
Blackboard blackboard;
recursiveVisitor( root_node, [&status_by_node](const TreeNode* node)
{
node->setBlackboard( &blackboard ); // this method will exist in the future
}); |
|
great! thanks. Sorry for the delay in this. |
|
|
Hi,
this pretty large PR introduce the ability (optional) to create a Tree at run-time loading it from an XML.
For simplicity, I included in the 3rdparty directory a popular library to parse XMLs.
You can see an example of XML here.
Hopefully the code in the unit test is self explaining ;)
User must register actions into the class BehaviorTreeFactory as shown here and here.
After that, an instance of a node can be created using the method instantiateTreeNode.
The XML parser use the factory to create the entire Tree. Ignore the part related to BehaviorTreeMetaModel for the time being...
As discussed, Actions and Decorators can have parameters. Since this parameters for the time being are read from XML, they are a pair of [attribute/value], both strings. We call them NodeParameters.
Since the core library can not know all the possible ways in which a parameter can be parsed, it just assumes that it is up to the user's code to parse the string. You can see an example in DecoratorRetryNode.
.... I just realized I didn't included in the unit test how to use these NodeParameters, whooops....
If you have any suggestion, doubt, request, let me know.
